Reolink 36 Channel Network Video Recorder

REOLINK 36 Channel Network Video Recorder for Security Camera System, Work with 12MP/4K/5MP/4MP HD Reolink IP Cameras NVR, Integrated O/I Alarm System, 3 HDD Bays, No HDD Included, RLN36

ONLY WORK WITH REOLINK IP CAMERAS: Work perfectly with all Reolink PoE 12MP/4K/5MP/4MP cameras and Reolink WiFi cameras with DC power (Battery-powered Cams are not supported), such as RLC-1212A, RLC1224A, RLC-823A 16X, Trackmix PoE, Duo 2 PoE, 823A, 811A, 810A, 820A, 842A, 510A, 520A, Doorbell PoE, E1 Outdoor cameras. Manage up to 36 Reolink IP cameras simultaneously easily.

EXPAND YOUR SYSTEM WITH POE SWITCHES: By connecting up to four PoE switches to the LAN ports of the NVR, you can extend your system for broader coverage and higher performance. Separating 36 cameras to 4 PoE switches, then connecting the PoE Switches to the RLN36 for integrated management, your 4K security system can be accessed with no latency with or without internet.

3 HDD BAYS, BUSINESS-GRADE STORAGE: The RLN36 network video recorder contains three HDD bays with each supporting up to 16TB HDD (NO HDD included). With 48TB storage in total and 36 IP cameras recording 24/7 at 6Mbps, the HDDs can last around 20 days. For a list of the recommended HDDs, please refer to the FAQ/Video page for more details.

UPGRADED DESIGN, FASTER DATA TRANSFER: This Reolink NVR can be plugged into mic/speaker devices to hear & talk back to whoever you catch on the monitor via Reolink cameras with two-way talk function. The RCA male-to-female converters are required (not included). The USB 3.0 port will help you back up important footage from your HDD to your portable hard drive efficiently.

FULL INTEGRATION WITH SMART REOLINK CAMS: The RLN36 NVR can integrate human/vehicle detection & playback from Reolink IP cams to build an intelligent system. By adding more Reolink cameras with optical zoom, auto-tracking, two-way talk, motion-triggered spotlights features, you can even build a cutting-edge home security system on your own.

Product Description
Now you can separate up to 36 Reolink IP cameras to 4 PoE switches, then connecting the PoE Switches to the RLN36 for integrated management with broader coverage and higher performance. NOTE: The PoE switches need separate power supplies.
With or Without Internet
This PoE NVR can be used without being connected to the internet for local recording and live viewing. However, an internet connection is required to enable remote viewing, motion push notifications.
Faster Connection Than You Imagine
RLN36 NVR is embedded with HEVC, 1Gbps LAN ports & WAN port that can provide real-time connection to your 4K security cameras smoother than ever. Hassles saved for loading & caching, more peace of mind gained.
1x USB 3.0 Port for Data Transfer
Need to backup a large capacity of footage to your device from time to time? The USB 3.0 port on this RLN36 network video recorder will solve your worries. An upgrade to the USB port will help transfer your data with high efficiency .
Reolink 36CH Network Video Recorder Specifications Power Supply DC 12V/5.4A Working Environment Temperature: -10°C ~+55°C (14°F~131°F); Humidity: 10%~90% Power Consumption <10W（Without HDD & PoE） Ethernet Ports No PoE Port；4 x RJ-45, 10/100/1000 Mbps self-adaptive (for IP cameras)；1 x RJ-45, 10/100/1000 Mbps self-adaptive (for LAN/WAN)； IP Camera Input Supports up to 36 channels of IPC access; each channel up to 12MP input Video Output HDMI：3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768; VGA:1920x1080, 1280x1024, 1280x720, 1024x768 Two-Way Talk Built-in audio in & out ports Video Compression H.265, H.264 Live View/Playback Resolution 4608*1728,4512*2512,4096X3072, 3840*2160, 2560x1920, 2560*1440, 2048*1536, 2304*1296,1080P, 720P Synchronous Playback 1-4 channels Supported Modes Person/vehicle detection; motion-triggered detection; 24/7 recording Storage 3 SATA ports for 3 HDDs (optional), No External HDD; Max. Capacity 48TB (Max. 16TB HDD for each SATA) Max. User Access 20 Users (1 admin account & 19 user accounts); supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams Browsers Supported Edge, Firefox, Chrome, Safari OS Supported PC: Windows, Mac OS; Smart phone: iOS, Android Weight/Dimensions (mm): 2.26Kg; 330 x 48 x 310mm Recording 24/7 or motion events continuously to Built-in 4TB HDD 24/7 or motion events to microSD card (not included) 24/7 or motion events to microSD card (not included) 24/7 or motion events to microSD card (not included) 24/7 or motion events to microSD card (not included) 24/7 or motion events to microSD card (not included) NVR Channel 16CH / / / / / NVR Pre-installed HDD 4TB / / / / / Resolution Depends on the camera 8MP(3840x2160) 8MP(3840x2160) 8MP(3840x2160) 8MP(3840x2160) 8MP(4608x1728) Zoom Depends on the camera Digital zoom Digital zoom 16X Optical Zoom 5X Optical Zoom Digital zoom Pan Tilt Depends on the camera P:180°, T:10°~55°(Manual Tilt) / 360°Pan, 90°Tilt 360°Pan, 90°Tilt / Angle of View Depends on the camera H: 88.8° V: 45.2° D:106.2° H: 109° - 43°, V: 58° - 25° H:54.2° - 3.6° V:41.7°-2.1° H: 105°-31°, V: 55°-17° H: 180°, V: 60° Smart Human/Vehicle Detection Depends on the camera ✓ ✓ ✓ ✓ ✓ Waterproof Depends on the camera ✓ ✓ ✓ ✓ ✓ Item model number RLN36 Media Format Digital Video HDD Product Dimensions 12.99 x 1.89 x 12.2 inches Country of Origin China Item Weight 7.11 pounds Connectivity Technology USB Number of Channels 36 Item Dimensions LxWxH 12.99 x 1.89 x 12.2 inches Brand REOLINK Shipping
